Total length (during transportation) (mm)

3982

Total width (transportation/operation) (mm)

1300/1500

Total height (during transportation) (mm)

2380

Pushing Shovel width (Shrinking/Stretching) (mm)

1300/1500

Height of bulldozer shovel (mm)

292

Track gauge (mm)

1050/1250

Distance from the center of rotation to the tail of the track (mm)

930

Width of exhibition strip board (mm)

250

Ground clearance (mm)

170

Standard bucket width (with/without side teeth) (mm)

460/410

Track length (mm)

1860

Wheel spacing (mm)

1475

Total machine weight(kg)

2590

Bucket capacity(m³)

0.066

Engine model

3TNV76-P

Displacement(L(cc))

1.116

Rated power(kw/h)

15

Bucket digging force(KN)

18.4

Maximum excavation height(mm)

4122

Maximum dumping height(mm)

2882

Maximum excavation depth(mm)

2820

Maximum vertical arm excavation depth(mm)

2300

Maximum excavation distance(mm)

4352

Minimum turning radius at the front end(mm)

2004

Minimum turning radius at the rear end(mm)

710

Maximum excavation ground distance(mm)

4246

Maximum bulldozing height(mm)

340

Maximum bulldozing depth(mm)

270

Horizontal left shift of bucket(mm)

620

The bucket moves horizontally to the right(mm)

590

Walking speed (high/low)(km/h)

4.2/2.4

Rotation speed(min)

9.5

Swing angle(degree)

75/55

Gradability(degree)

58(30)

Ground pressure(kpa)

28.4(0.29)

Fuel tank capacity(L)

28
