Power type

-

Battery

Front wheel track

mm

1010

Rated liting capacity

KG

3500

Rear wheel track

mm

780

Load center distance

mm

500

Minimum ground clearance

mm

150

With fork

mm

3850

Maximum lifting height

m

3-6

Without fork

mm

2700

Lift lever adjustment range

mm

1040

Fullwidth

mm

1200

Minimum turning radius(outer side)

mm

2315

No lifting of the mast height

mm

2100

Minimum right-angle passage width

mm

3995

Height of the roof guard

mm

2100

Tire size (front)

mm

23*9-10

Maximum height during operation

m

3 - 6

Tire size(rear)

mm

18*7-8

Distance from the seat surface to the

mm

1000

Lead-acid battery voltage/capacity

V/Ah

Lithium battery

Front

mm

1260

Drive motor power

Kw

7.5

suspension travel

mm

350

Oil pump motor power

kw

10

Rear suspension travel

mm

365

-

-

-
