Rated lifting capacity

kg

4000

-

-

-

Without fork

mm

3000

Maximum lifting height without load

mm

3000

With fork

mm

4070

Free lifting height

mm

100

Wheel width

mm

1250

Lift angle (front/rear)

(°)

5/10

Frame width

mm

1300

Overall machine weight in standard unloaded state

kg

5800

Lifting door height

mm

2250

Maximum lifting speed without load

mm/s

230

Guardrail height

mm

2250

Maximum lifting speed with fullload

-

200

Maximum working height

mm

4200

Minimum turning radius

mm

2550

Axle spacing

mm

1900

No-load maximum operating speed

km/h

14

Front suspension distance

mm

350

Loaded maximum operating speed

-

12

Front wheel distance

mm

1100

Loaded maximum climbing gradient

%

12

Rear wheel distance

mm

1000

Center of load distance

mm

500

Minimum ground clearance of the mast

mm

105/110

Boost motor power

kw

18KW
